FX5UC series CPU unitFX5UC-32MT/DSS

The Melsec IQ-F series is equipped with a CPU that can process high-speed processing of 34ns of instructions (LD instructions).
In addition, structured programs, multiple program execution, ST language, FB, etc. are available.
Remote I/O (CC-LINK, AnywireasLink and Bitty Series) can control up to 512 points.
By connecting a simple motion unit, it is possible to position it corresponding to SSCNET II/h.
In the table system program, it can be used by combining a straight -line interpolation, a two -axis circular arc, a constant sending, and a continuous trajectory control.
Incorporated 2 -bit analog voltage input and 1ch analog voltage output.
You can use it only by setting parameter without a program.
You can easily set the numerical shift, scaling settings, and warning output settings with parameters.
The Ethernet port supports up to eight connections on the network and can be connected to a computer or device.
In addition, it can support seamless SLMP communication with the upper device.
Built-in RS-485 ports, up to 50 meters and up to 16 units with Mitsubishi Electric general-purpose inverter (can control with six inverter-only orders).
It also supports the modbus function, and can connect up to 32 stations with MODBUS compatible devices such as sequencers, sensors, and temperature controlers.
Built -in SD memory card slot that is convenient for updating programs and mass production of equipment.
Data can be logged on the SD memory card, which is useful for analyzing the condition of the device and production status.
The MELSEC IQ-F series achieves a 1.5K word/MS (about 150 times compared to the FX3U ratio), along with high-speed CPUs.
You can maximize your abilities when using an intelligent function unit with a large amount of communication data.
Equipped with a RUN/STOP/RESET switch.
It is efficient because it can be restarted without dropping the power even when debugging.
Prevents the stolen, tampering, erroneous operation, and unauthorized execution of data from a third party with a security function
(block password, file password, remote password, security key authentication).
In the MELSEC IQ-F series, programs and devices are kept in a memory that does not require battery such as flash ROM *.
*: It is possible to increase the capacity of the device by using an optional battery.
