MITUTOYO
MITUTOYO M310-50 102 Series Standard Outside Micrometer M300
Regular price
$3,213.00 TWD
Regular price
$3,382.00 TWD
Sale price
$3,213.00 TWD
Unit price
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
◆Specifications and dimensional information under specification
Calibration certificate No Type Standard micrometer
Display method Analog Maximum measuring length (range selection) (mm) 26 to 50
Waterproof function No Measurement data output terminal Yes No
Measuring range (mm) 25 to 50 Instrumental error (μm) ±2
Scale interval (mm) 0.01 Flatness (µm) 0.6
Ratchet stop Measuring surface Carbide tip
Code No., Code, Part No. 102-302 Trusco Code 219-5968
Parallelism (µm) 2 Specifications Frame: painted, with heatproof cover
Size a (mm) 8 Size b (mm) 55.3
Calibration certificate No Type Standard micrometer
Display method Analog Maximum measuring length (range selection) (mm) 26 to 50
Waterproof function No Measurement data output terminal Yes No
Measuring range (mm) 25 to 50 Instrumental error (μm) ±2
Scale interval (mm) 0.01 Flatness (µm) 0.6
Ratchet stop Measuring surface Carbide tip
Code No., Code, Part No. 102-302 Trusco Code 219-5968
Parallelism (µm) 2 Specifications Frame: painted, with heatproof cover
Size a (mm) 8 Size b (mm) 55.3
