• CONTEC DIO-48DX-USB [USB-compatible non-insuler type two-way digital input / output unit]
1 1

CONTEC

CONTEC DIO-48DX-USB [USB-compatible non-insuler type two-way digital input / output unit]

$21,026.00 TWD
$22,132.00 TWD $21,026.00 TWD
Sale Sold out
Tax included. Shipping calculated at checkout.

This product is a USB2.0 -compatible digital input / output unit that extends the two -way input / output function of the digital signal on a personal computer.It is equipped with 48 non -insulating TTL level input / output that operates equivalent to i8255 mode 0.Up to 48 points of the input signal can be used as interrupted input.Input / output switching can be performed in 8 -point units (4 points for some input / output) depending on the software.In addition, it has a digital filter function.



-
[Extended module]
Bus specification USB 2.0
Size X type
Used connector 1x 1.27mm pitch 96-pin (male)
[Digital input/output]
number of input points -
Output points -
two -way score 48 points
Response speed (input) 200nsec (max.)
Response speed (output) 200nsec (max.)
Operate voltage (input) 5VDC-TTL
Operate voltage (output) 5VDC-TTL
input circuit Non -insulated TTL level input (positive logic)
Output circuit Non -insulated TTL level output (positive logic)
Built -in power supply -
