CONTEC
CONTEC DIO-1616T-PE [PCI-E compatible digital input / output board]
Regular price
$332.53 USD
Regular price
$350.03 USD
Sale price
$332.53 USD
Unit price
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
This product is a PCI Express bus compatible board that extends the input / output function of the digital signal on a personal computer.It is equipped with 16 non -insulating TTL level input and 16 non -insulated open collector output, and can be used as interrupts.In addition, it is equipped with a digital filter function that prevents incorrect recognition of input signal.A Windows/Linux driver is attached.
-
| [Extended module] | |
|---|---|
| Bus specification | PCI Express |
| Size | Short size |
| Used connector | D-SUB 37-pin (female) |
| [Digital input/output] | |
| number of input points | 16 points |
| Output points | 16 points |
| two -way score | - |
| Response speed (input) | 200nsec (max.) |
| Response speed (output) | 200nsec (max.) |
| Operate voltage (input) | 5VDC-TTL |
| Operate voltage (output) | 5VDC-TTL |
| input circuit | Non -insulated TTL level input (negative portion) |
| Output circuit | Non -insulated TTL Open Collector Output (negative theory) |
| Built -in power supply | - |
